Mô tả sản phẩm
The XCT-series systems are manually loaded, automated X-ray CT systems which offer a solution for a variety of CT applications. These systems provide the highest possible flexibility in order to satisfy individual customer needs. Depending on the application, they can be equipped with different types of tubes and detectors to offer high-resolution or high-power solutions. Unlike most CT systems, the XCT-1000 features both volume analyzing and automatic processing of the slices. As the newest feature, this machine is available with a super high resolution setup, offering a CT voxel size less than 1µm. It is especially suitable for the inspection of small to medium production volumes or for the use in laboratory environments, production sampling or failure analysis. The applications range from consumer electronics and automotive li-ion batteries, component level inspection for wire bonds, micro-solder-joints on PCB‘s, casting parts and semiconductors.
Specifications
| System | |
|---|---|
| Footprint | 1735 mm (H) x 1620 mm (W) x 820 mm (D) |
| System Weight | 1.500 kg |
| Power Consumption | max. 6kW |
| Line Voltage | 220 VAC, single phase, 16A |
| Operation Temperature | 15° - 28° C optimal 20° - 25° C |
| Inspection features | |
|---|---|
| Max. sample size | 150 mm x 150 mm |
| Max. inspection area | 150 mm x 150 mm |
| FDD (focus detector distance) | 130-700 mm |
| FOD (focus object distance) | 54-650 mm |
| Max. sample weight | 5 kg |
| Options |
|---|
| Barcodereader |
| Volume Graphics software license |
| Custom features |
|
X-ray System Features
|
 |
|
|
Highlights
|
.jpg) |
|
|
Depending on the type of product & inspection task Setups:
|
 |
