CIQTEK SEM5000 is a high-resolution, feature-rich field emission scanning electron microscope (FE-SEM, FEG SEM).
Advanced column design, high voltage tunneling technology (SuperTunnel), low aberration non-leakage magnetic objective lens design, to achieve low-voltage high-resolution imaging, while magnetic samples can be applied. Optical navigation, advanced automatic functions, well-designed human-machine interaction, and optimized operation.
Whether experienced or not, one can quickly get started with high-resolution shooting tasks.

Parameters

Key Parameters	Resolution	1.0 nm @ 15 kV, SE 1.5 nm @ 1 kV, SE 0.8 nm @ 30 kV, STEM
	Acceleration voltage	20 V ~ 30 kV
	Magnification	1 ~ 2,500,000 x
	Electron Gun	High brightness Schottky Field Emission Electron Gun
Sample Chamber	Vacuum System	Fully automatic control, oil-free vacuum system
	Camera	Dual Cameras (Optical navigation + in-bin monitor)
	Distance	X: 120 mm, Y: 115 mm, Z: 50 mm T: -10°～ +90°, R: 360° (*Optional extra-large bin version available)
Detectors and Extensions	Standard	The high-angle electronic detector in the lens column The side low-angle electronic detector
Detectors and Extensions	Optional	Flush-mounted mid-angle backscattered electron detector Automatic retractable scanning transmission electron microscopy (STEM) detector Sample exchange chamber High-speed beam gate and electron beam exposure Energy dispersive spectroscopy (EDS/EDX) Electron Backscatter Diffraction (EBSD) Electron-beam-induced current (EBIC) Cathodoluminescence (CL) High and low temperature in-situ stretching table nanoManipulator Large-Scale Image Stitching Trackball & Knob Control Panel
Software	Operating System	Windows
	Navigation	Optical Navigation, Gesture Quick Navigation
	Automatic Functions	Auto Brightness Contrast, Auto Focus, Automatic Dissipation
