Mô tả sản phẩm

Place of Origin:	China
Brand Name:	UNICOMP
Certification:	CE
Model Number:	UNC225π

Payment & Shipping Terms:

Minimum Order Quantity:	1Set
Price:	can negotiate
Packaging Details:	Wooden Case, Waterproof, Anti-collision
Delivery Time:	30 days
Payment Terms:	T/T, L/C
Supply Ability:	10 sets per month

Detailed Product Description

Color:	Orange	Name:	Pipelines X-ray
Application:	Steel Pipes, Aluminum Casting	Tube Voltage:	225KV
X-ray Leakage:	< 1uSv/h	Power Consumption:	9kW
High Light:	225KV NDT X Ray Machine Low Breakdown NDT X Ray Machine Automotive Aircraft Vessel X Ray Detector

Unicomp X ray NDT Machine Automotive Aircraft Vessel Inspection Systems UNC225π

Features:
● High reliable and long life,low breakdown
● High definition and resolution FPD
● C-arm fixture design enabling five-axis motion detection(optional automatic lift and descend)
● Multi-functional workstation,360°rotation and shift
● User friendly software design for easy interfacing can facilitate,customized software
● High penetration,Voltage up to 225KV,Maximum penetration thickness up to 25mm for "Fe"
● Detection area:Φ1200*1200mm
● Loading weight:300KG

Applications:
It is widely applied to inspect all kind of casting,NDT for air bubble,porosity and unwanted foreign.The equipment is applicable objects for NDT of cylinder welding defects and body,sidewall,lap,Crown steel cord and steel belt of tyre slag inclusion,crack,loosen and other flaws in hubs,pressure vessel,refractory material,bullet,boilr welded pipe and screwy pipe.

System Parameters
Dimensions	3200mm3873mm3277mm(LWH)
Equipment weight	8.5T
Power	9KW
Maximum penetration(AL)	150mm/25mm
Detection range	ɸ1200*1200mm
Load weight	300KG
Work environment	5-40° ≦80﹪HR
Install power	three-phase five-wire 380V power supply
X-ray leakage dose rate	≤1μSv/h
X-ray Generator
Tube voltage	225kv
Power	800w/1800w
Focal size	0.4mm/1.0mm
Detector
Imaging field	φ 215mm
Resolution	2.8 LP/mm
Detector (FPD Optional)
Image area	250mm x 300mm
Pixel matrix	1792 x 2176
Pixel size	139μm
Frame rate	9 fps(1x1)30 fps(2 x 2)
Software Functions
Image processing	Brightness and contrast adjustment; stacking frames; window width and window position adjustment; image enhancement, filter, sharpening, invert, relief and bubble measure; move, zoom in, zoom out; display image scaling; display of the mouse pointer image coordinate and the gray value
Image measurement	Distance, radius, polygon, angle measurement; arrows and text labels; save the processed image;
Others	Setting the camera rotating screen; exposure time; static,dynamic image display and save, video display and save
Additional Function
Catch tool car can be completely out of the protective lead room, easy up and down lifting. X-Ray tube can be extended into the detected parts, single / double check through the material everywhere. Drive motor frequency control, unlimited speed control. Lead door with anti-folder function and chain protection, protection equipment and staff. Voltage regulator, isolation, filtering, grounding and other protective functions are complete. Set aside industrial cloud interface, data and pictures in real time upload, with traceability and large data analysis function (optional).
