5KW AX8800 Stand Alone X Ray Machine 100kv For Plate Aligenment

Danh mục:

Unicomp

Từ khóa:

xray 3d sửa máy x ray công nghiệp , sửa máy x ray công nghiệp , máy kiểm tra x ray , kiểm định an toàn phóng xạ , máy x ray công nghiệp , cho thuê máy x ray , mua bán máy x ray cũ mới , máy x ray cũ mới , xray 3d , x ray 3d , xrf , xrf cũ mới , sửa máy đo xrf

Vận chuyển giao hàng toàn quốc

Phương thức thanh toán linh hoạt

Gọi ngay 0974692294 để mua và đặt hàng nhanh chóng

Mô tả sản phẩm

Place of Origin:	China
Brand Name:	Unicomp
Certification:	ISO9001，ISO14004,OHSAS18001,
Model Number:	AX8800

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	Can negotiate
Packaging Details:	Wooden Case
Delivery Time:	One month
Payment Terms:	T/T
Supply Ability:	100Sets/Month

Detailed Product Description

Dimension（L×W×H）:	1602mmX1296mmX2148mm	Weight:	2T
Power:	5KW	Max.Voltage:	100kv
Resolution:	110 Lp/cm	Focal Spot Size:	5um
High Light:	Stand Alone X Ray Machine 5KW X Ray Machine 100kv X Ray Inspection Scanner

Cabinet Lithium Battery Automatic X-ray Inspection Machine AX8800

Features:
● Off-line lithium battery detection equipment
● 100KV 5μm closed X-ray tube, Hi-resolution detector
● X-ray tube and detector can be programmed to move to Z Axis
● Automatic control of all the moving parts, Automatic programming
● Convenient target point positioning system
● Automation software judgments detection

Applications:
●Lithium battery pole piece solder joint defect detection,
●Lithium battery batteries coiling case detection,
●BGA , CSP , LED , Flip Chip , Semiconductor,
●Battery Industry , Small Metal Casting,
●Electronic Connector Module,
●Aerospace Components , Photovoltaic Industry ,
●Other Special Industries.

Aftersales service:
Ø A professional service team
Ø Country-wide network
Ø 24/7 hotline
Ø Onsite installation, debugging and training services
Ø Scheduled call & visits
Ø Life-long free software upgrading

Company Introduction:

15 years focused on X-ray technology R & D and equipment mfg.
A national Hi-tech enterprise with international vision
3 modern R & D and manufacturing factories, 2 software companies
240 patents & 30 software copyright
300 professional R & D engineers, sales and service staff
Company certified by ISO9001, ISO14001 and OHSAS18001 system
Products complied with CE, FDA and passed Chinese MPS testing
Provincial Engineering Technology Research Center
Provincial science and technology award
Monthly production capacity up to 500 sets

System Parameters	Dimension(L×W×H)	1602mmX1296mmX2148mm
	Weight	2T
	Working Environment	0～40℃
	Power	5KW
	Accuracy	±60μm
	Operating Mode	Off-line
X-ray Tube	Type	Closed
	Max.Voltage	100kv
	Max.Current	0.2mA
	Focal Spot Size	5um
	Quantity	1
Image Detector	Type	Image Intensifier
	Resolution	110 Lp/cm
	Size	4”
	Quantity	1
Applied to		Lithium Battery , Semiconductor
Max.Capacity		--
Operation Ratio		≥95%
Applicable Size		Detection area : 390mm*440mm
Items		Internal Flaw
Customer Cases		FOXCCON/SAMSUNG/HUWEI
Equipment Features		Lithium battery pole piece solder joint defect detection ; Lithium battery cell coiling case detection ; BGA, CSP, LED, Flip Chip, Semiconductor ; Electronic Connector Module ; Automotive Electronics ; Solar Energy , Photovoltaic Industry ; *Other special industries
