NDT Unicomp X Ray Systems UNC160-C-L X Ray Testing Of Castings 160KV

Danh mục:

Unicomp

Từ khóa:

xray3dsửamáyxraycôngnghiệp , sửamáyxraycôngnghiệp , máykiểmtraxray , kiểmđịnhantoànphóngxạ , máyxraycôngnghiệp , chothuêmáyxray , muabánmáyxraycũmới , máyxraycũmới , xray3d , xrf , xrfcũmới , sửamáyđoxrf

Vận chuyển giao hàng toàn quốc

Phương thức thanh toán linh hoạt

Gọi ngay 0974692294 để mua và đặt hàng nhanh chóng

Mô tả sản phẩm

Place of Origin:	China
Brand Name:	UNICOMP
Certification:	CE
Model Number:	UNC160-C-L

Payment & Shipping Terms:

Minimum Order Quantity:	1Set
Price:	can negotiate
Packaging Details:	Wooden Case, Waterproof, Anti-collision
Delivery Time:	30 days
Payment Terms:	T/T, L/C
Supply Ability:	10 sets per month

Detailed Product Description

Name:	Industrial X-ray Inspection Systems	Application:	Aluminum Casting, Iron Casting, Auto Parts, Wheels, Metal Products, Refractory Materials
Tube Voltage:	160KV To 450KV Optional	Size:	1650 Mm × 2014 Mm× 2097 Mm
X-ray Leakage:	< 1uSv/h	Weight:	2.5T
High Light:	NDT Unicomp X Ray Systems Castings Testing Unicomp X Ray 160KV Electronics X Ray Machine

NDT Unicomp X-Ray Systems UNC160-C-L Die Castings Pipe Inspection

Features:

* The implementation of automatic location detection
* Automatic identification of defect detection
* The unqualified product identification marking
* OK and NG are sorting and recognition
* High contrast, high quality image detection
* Extended-modular design, strong, automatic loading and unloading
* Adopt the design of transmission mechanism of high speed positioning, multi axis motion detection method
* Custom fixture
* Can be in accordance with customer docking automatic production line, unattended operation
* The high detection efficiency, to achieve full detection
* The operation is simple and convenient

Applications:

The online detection of all kinds of aluminum castings, ball graphite cast iron, auto parts, hardware products.

130KV, 160KV, 225KV,320KV, 450KV, X-ray Detection System

Adjustment the range of X-ray apparatus and image forming apparatus	600mm～800mm
Lifting range of arc type detection arm	0～300mm
The movable range of the detection platform in the X axis direction	0～250mm
The movable range of the detection platform in the Y axis direction	0～250mm
Loading capacity of test platform	≤10kg
Right and left swing angle range of arc type detection arm	±15°
Front and back swing angle range of arc detection arm	±15°
Conveying stroke of feeding / discharging manipulator	875mm
Operating speed of feeding / discharging manipulator	About 500mm/s
Operating speed of feeding / discharging line	About 262mm/s
Size of the protective lead room (L * w * h)	1650mm×2014mm×2097mm (Outer dimension)
Weight of protective lead room	About 2.5t
Maximum size specification of equipment available for inspection	520mm×464mm×176mm
