220VAC CNC Programmable Electronics X Ray Machine 5um 90kV AX8200

Danh mục:

Unicomp

Từ khóa:

xray3dsửamáyxraycôngnghiệp , sửamáyxraycôngnghiệp , máykiểmtraxray , kiểmđịnhantoànphóngxạ , máyxraycôngnghiệp , chothuêmáyxray , muabánmáyxraycũmới , máyxraycũmới , xray3d , xrf , xrfcũmới , sửamáyđoxrf

Vận chuyển giao hàng toàn quốc

Phương thức thanh toán linh hoạt

Gọi ngay 0974692294 để mua và đặt hàng nhanh chóng

Mô tả sản phẩm

Place of Origin:	China
Brand Name:	UNICOMP
Certification:	CE, FDA
Model Number:	AX8200

Payment & Shipping Terms:

Minimum Order Quantity:	1Set
Price:	can negotiate
Packaging Details:	Wooden Case, Waterproof, Anti-collision
Delivery Time:	30 days
Payment Terms:	T/T, L/C
Supply Ability:	300 sets per month

Detailed Product Description

Name:	Electronics X Ray Machine	Application:	SMT, EMS,BGA, Electronics, CSP , LED , Flip Chip , Semiconductor
Tube Voltage:	100KV	Max.Voltage:	90kV/100kV
X Ray Tube Type:	Closed	X-ray Leakage:	< 1uSv/h
High Light:	CNC Programmable Electronics X Ray Machine 220VAC Electronics X Ray Machine 5um X Ray Inspection Equipment

SMT X-Ray Closed 5g Chipset Electronic Resistance Inspection Machine AX8200

Applications

BGA Inspection
Inspection of over molded electrical connectors
Encapsulated components
Aluminum die castings
Molded plastic components
Ceramics
Aerospace components
Electrical / mechanical components
Electronic components
SMT assemblies
Pharmaceuticals
Automotive assemblies
Agriculture
Counterfeit inspection
Cell phone battery inspection

Item	Definition	Specs
System Parameters	Size	1080(L)x1180(W)x1730(H)mm
	Weight	1150kg
	Power	220VAC/50Hz
	Power Consumption	0.8kW
X-ray Tube	Type	Closed
	Max.Voltage	90kV/100kV
	Max.Power	8W
	Spot Size	5μm
X-ray System	Intensifier	4"Image Intensifier
	Monitor	22"LCD
	System Magnification	600x
Detection Region	Max.Loading Size	510mm x 420mm
Detection Region	Max.Inspection Area	435mm x 385mm
X-ray Leakage		< 1uSv/h

The AX-8200 machine is designed to provide high resolution x-ray imaging primarily for the electronics industry. This versatile system is effective for many applications within the PCB manufacturing process. This includes BGA, CSP, QFN, Flip Chip, COB and the wide range of SMT components. The AX-8200 is a powerful support tool for process development, process monitoring and refinement of the rework operation. Supported by a powerful and easy to use software interface, the AX-8200 is capable of addressing small and large volume factory requirements. (Contact us for details)

OUR SERVICE

Your inquiry will be replied in 12 hours.
Original Manufacture to customers, with competitive price.
We provide one year warranty, free training and whole life technology support.
We can arrange the shipment by air, DHL,Fedex, UPS, and by Sea,etc for you,and will give you the tracking NO. after shipment.
Well-trained and Professional after-sales service team to support you.
Manual will package with machine . It will show you how to use machine step by step.
Items are only shipped after payment is received.
